Small Rubber Stoppers for Lateral Packers

Small Rubber Stoppers for Lateral Packers
CategoriesPipe Stopper
AlbumView larger image
BrandIPS
ModelHP
Terms of PaymentT/T, Western Union, MoneyGram
Download DOC
Update Time2018-12-11
Detail Information


IPS supplies best quality Rubber Stoppers to seal sewer pipe ends or gauge pressure for drain and sewer pipe systems.They have been widely applied in China for plumbing works.

Small Rubber Stoppers lateral packers are used for repairing of the smallest diameter of hause pipeline. For easy manipulation in pipe bends the rigid ends of packer are made as short as possible. The effective surface ranges from 300 mm to 1300 mm.


Small  Rubber Stoppers for Lateral Packers

Small Lateral Packers


Type

Part No.

Pipe diameter

Rubber body diameter

Rubber body length

Total length

Weight

Operating pressure

mm

mm

mm

mm

kg

bar

HP 3/4 0,4

7330

30–40

25

400

450

0,30

3,0

HP 3/4 0,6

7341

30–40

25

600

650

0,40

3,0

HP 3/4 1

7342

30–40

25

1000

1050

0,60

3,0

HP 3/4 1,5

7343

30–40

25

1500

1550

0,90

3,0

HP 3,5/5 – 0,4

7339

35–50

30

400

450

0,35

3,0

HP 3,5/5 – 0,6

7340

35–50

30

600

650

0,45

3,0

HP 3,5/5 1

7344

35–50

30

1000

1050

0,65

3,0

HP 3,5/5 – 1,5

7345

35–50

30

1500

1550

0,95

3,0



Small  Rubber Stoppers for Lateral Packers
