Lateral packers are suitable for maintaining and repairing small- diameter pipes especially with house piping. They consist of a rubberized- fabric tube rounded at both its endsto facilitate manipulation in pipe bends. The effective surface ranges from 500 to 3700 mm.

Bend Packers OP With Sliding And Filling Rods For Rehabilitation Packers


Lateral Packers
HP


Type

Part No.

Pipe diameter

Rubber body diameter

Rubber body length

Total length

Weight

Operating pressure

mm

mm

mm

mm

kg

bar

HP 5/7–0,6

7331

50–70

35

600

710

0,55

3,0

HP 5/7–1

7332

50–70

35

1000

1110

0,65

3,0

HP 5/7–1,5

7336

50–70

35

1500

1610

0,75

3,0

HP 5/7–2

7333

50–70

35

2000

2110

0,9

3,0

HP 5/7–2,5

7335

50–70

35

2500

2610

1,05

3,0

HP 5/7–3

7337

50–70

35

3000

3110

1,2

3,0

HP 7/10–0,6

7313

70–100

45

600

720

0,65

3,0

HP 7/10–1

7314

70–100

45

1000

1120

0,75

3,0

HP 7/10–1,5

7315

70–100

45

1500

1620

0,85

3,0

HP 7/10–2

7316

70–100

45

2000

2120

0,95

3,0

HP 7/10–2,5

7319

70–100

45

2500

2620

1,2

3,0

HP 7/10–3

7317

70–100

45

3000

3120

1,5

3,0

HP 7/10–3,5

7320

70–100

45

3500

3620

1,65

3,0

HP 7/10–4

7318

70–100

45

4000

4120

1,8

3,0

HP 10/15–0,6

7301

100–150

65

600

720

1,1

2,5

HP 10/15–1

7302

100–150

65

1000

1120

1,4

2,5

HP 10/15–1,5

7303

100–150

65

1500

1620

1,8

2,5

HP 10/15–2

7304

100–150

65

2000

2120

2,1

2,5

HP 10/15–2,5

7321

100–150

65

2500

2620

2,5

2,5

HP 10/15–3

7309

100–150

65

3000

3120

2,9

2,5

HP 10/15–3,5

7322

100–150

65

3500

3620

3,3

2,5

HP 10/15–4

7311

100–150

65

4000

4120

3,7

2,5

HP 10/20–0,6

7348

100–200

68

600

720

1,55

2,5

HP 10/20–1

7349

100–200

68

1000

1120

2,05

2,5

HP 10/20–1,5

7350

100–200

68

1500

1620

2,65

2,5

HP 10/20–2

7351

100–200

68

2000

2120

3,25

2,5

HP 10/20–2,5

7352

100–200

68

2500

2620

3,85

2,5

HP 10/20–3

7353

100–200

68

3000

3120

4,45

2,5

HP 10/20–3,5

7354

100–200

68

3500

3620

5,05

2,5

HP 10/20–4

7355

100–200

68

4000

4120

5,65

2,5

HP 15/25–0,6

7305

150–250

105

600

730

2,5

2,0

HP 15/25–1

7306

150–250

105

1000

1130

3,2

2,0

HP 15/25–1,5

7307

150–250

105

1500

1630

4,0

2,0

HP 15/25–2

7308

150–250

105

2000

2130

4,8

2,0

HP 15/25–2,5

7323

150–250

105

2500

2630

5,6

2,0

HP 15/25–3

7310

150–250

105

3000

3130

6,4

2,0

HP 15/25–3,5

7324

150–250

105

3500

3630

7,2

2,0

HP 15/25–4

7312

150–250

105

4000

4130

8,0

2,0
