Bend packers thanks to their construction are suitable for repairing in bend parts of pipelines at an angle from 45° to 90°. This construction and excellent rubber material of packers ensure, that the repair part is plain and without bumps.

Bend Packers OP With Sliding And Filling Rods For Sewer Rehabilitation

Type

Part No.

Pipe diameter

Rubber body diameter

Rubber body length

Total length

Weight

Operating pressure

mm

mm

mm

mm

kg

bar

OP 5/7 0,4

7515

50–70

35

400

510

0,5

2,0

OP 5/7 0,6

7512

50–70

35

600

710

0,55

2,0

OP 5/7 1

7516

50–70

35

1000

1110

0,65

2,0

OP 7/9 0,6

7501

70–90

45

600

720

0,7

2,0

OP 7/9 1

7502

70–90

45

1000

1120

0,8

2,0

OP 7/9 1,5

7503

70–90

45

1500

1620

0,9

2,0

OP 8/11 1

7513

80–110

56

1000

1120

1,1

2,0

OP 8/11 1,5

7514

80–110

56

1500

1620

1,2

2,0

OP 10/13 1

7506

100–130

65

1000

1120

1,4

2,0

OP 10/13 1,5

7507

100–130

65

1500

1620

1,7

2,0

OP 14/17 1

7508

140–170

86

1000

1130

3,3

2,0

OP 14/17 1,5

7509

140–170

86

1500

1630

4

2,0

OP 18/21 1

7504

180–210

107

1000

1130

5

2,0

OP 18/21 1,5

7505

180–210

107

1500

1630

6

2,0


Sliding and filling rods for rehabilitation packers


Part–No.     Description


2129

Sliding and filling rod

0,5 m – 20 G

2130

Sliding and filling rod

1 m – 20 G

2127

Sliding and filling rod

1,5 m – 20 G

2120

Sliding and filling rod

2 m – 20 G

2131

Sliding and filling rod

2,5 m – 20 G

2132

Sliding and filling rod

3 m – 20 G


Part–No.   Description

2037

Sliding and filling rod

0,5 m – 20 KR

2040

Sliding and filling rod

1 m – 20 KR

2041

Sliding and filling rod

1,5 m – 20 KR

2038

Sliding and filling rod

2 m – 20 KR
