Flexible packers FP are provided with a single-layer rubberized-fabric sleeve with metal faces with wheels at both its ends at an angle of 120°.The wheels ensure the stability of the packer in the pipeline. Its design allows water to flow freely during the repair. The effective surface ranges from 600 to 3500 mm. Their flexibility allows easy installationin the pipeline.


FP Flexible Rubber Packers Plugs For Plastic BarrelFlexible Packers FP

Type

Part No.

Pipe diameter

Rubber body diameter

Rubber body length

Total length

Weight

Operating pressure

Bypass

mm

mm

mm

mm

kg

bar

FP 10/15–1

7209

100–150

65

1000

1120

1,9

2,5

FP 10/15–1,5

7211

100–150

65

1500

1620

2,3

2,5

FP 10/15–2

7210

100–150

65

2000

2120

2,6

2,5

FP 10/15–2,5

7212

100–150

65

2500

2620

2,9

2,5

FP 10/15–3

7213

100–150

65

3000

3120

3,3

2,5

FP 10/15–3,5

7214

100–150

65

3500

3620

3,7

2,5

FP 10/15–4

7215

100–150

65

4000

4120

4,0

2,5

FP 15/25–1

7201

150–250

105

1000

1180

5,0

2,0

2”

FP 15/25–1,5

7216

150–250

105

1500

1680

6,3

2,0

2”

FP 15/25–2

7202

150–250

105

2000

2180

7,5

2,0

2”

FP 15/25–2,5

7217

150–250

105

2500

2680

8,8

2,0

2”

FP 15/25–3

7218

150–250

105

3000

3180

10,0

2,0

2”

FP 15/25–3,5

7219

150–250

105

3500

3680

11,3

2,0

2”

FP 15/25–4

7220

150–250

105

4000

4180

12,5

2,0

2”

FP 20/30–1

7236

200–300

144

1100

1340

10,0

1,5

2“

FP 20/30–1,5

7237

200–300

144

1600

1840

11,1

1,5

2“

FP 20/30–2

7238

200–300

144

2000

2240

12,2

1,5

2“

FP 20/30–2,5

7239

200–300

144

2600

2840

13,3

1,5

2“

FP 20/30–3

7240

200–300

144

3000

3240

14,4

1,5

2“

FP 20/30–3,5

7241

200 –300

144

3600

3840

15,5

1,5

2“

FP 20/30–4

7242

200–300

144

4000

4240

16,6

1,5

2“

FP 30/40–1

7203

300–400

235

1100

1340

19

1,5

2”

FP 30/40–1,5

7221

300–400

235

1600

1840

21

1,5

2”

FP 30/40–2

7204

300–400

235

2000

2240

23

1,5

2”

FP 30/40–2,5

7222

300–400

235

2600

2840

26

1,5

2”

FP 30/40–3

7223

300–400

235

3000

3240

28

1,5

2”

FP 30/40–3,5

7224

300–400

235

3600

3840

31

1,5

2”

FP 30/40–4

7225

300–400

235

4000

4240

33

1,5

2”

FP 45/60–1

7205

450–600

365

1200

1440

36

1,0

4”

FP 45/60–1,5

7226

450–600

365

1700

1940

40

1,0

4”

FP 45/60–2

7206

450–600

365

2000

2240

42

1,0

4”

FP 45/60–2,5

7227

450–600

365

2700

2940

46

1,0

4”

FP 45/60–3

7228

450–600

365

3000

3240

49

1,0

4”

FP 60/80–1

7207

600–800

365

1400

1640

37,5

1,0

4”

FP 60/80–1,5

7229

600–800

365

1700

1940

41,5

1,0

4”

FP 60/80–2

7208

600–800

365

2000

2240

43,5

1,0

4”

FP 60/80–2,5

7230

600–800

365

2700

2940

47,5

1,0

4”

FP 60/80–3

7231

600–800

365

3000

3240

50,5

1,0

4”

FP 80/100–1,5

7235

800–1000

550

1800

2040

82

1,0

4“

FP 100/120–2

7534

1000–1200

550

2200

2440

88

1,0

4“
