ULK,PULK Cone Inflatable Drain Pipe Stoppers

ULK,PULK Cone Inflatable Drain Pipe Stoppers
CategoriesPipe Stopper
AlbumView larger image
BrandIPS
ModelULK,PULK
Terms of PaymentT/T, Western Union, MoneyGram
Download DOC
Update Time2018-12-11
Detail Information


Cone drain pipe stoppers have in comparison with classical pipe stoppers different construction, but their useis the same. They are mainly used during repair and maintenance work, accidents and the leak tests of pipe- lines. This construction allow their use for all profiles, also egg-shaped, rectangular and many any others.These pipe stoppers are made of quality rubber. Therefore they have good chemical resistence, high age-resistence, low weight, and they are simply reparable. The diameter of standard product line ranges from 150 to 2200 mm.

ULK,PULK Cone Inflatable Drain Pipe Stoppers

Cone Pipe Stoppers ULK

Type

ULK 15/40

ULK 25/60

ULK 40/100

ULK 50/120

ULK 60/140

ULK 70/160

ULK 120/220

Part - No.

1125

1120

1121

1126

1122

1123

1124

Pipe diameter

mm

150–400

250–600

400–1000

500–1200

600–1400

700–1600

1200–2200

Operating pressure

bar

1,0

1,0

1,0

1,0

1,0

1,0

1,0

Test pressure

bar

1,3

1,3

1,3

1,3

1,3

1,3

1,3

Back pressure

bar

0,5

0,5

0,5

0,5

0,5

0,5

0,5

Weight

kg

2

4,1

11

15

26

41

89



Cone Test Pipe Stoppers PULK

Type

PULK 15/40

PULK 25/60

PULK 40/100

PULK 50/120

PULK 60/140

PULK 70/160

PULK 120/220

Part - No.

1233

1228

1229

1234

1230

1231

1232

Pipe diameter

mm

150–400

250–600

400–1000

500–1200

600–1400

700–1600

1200–2200

Operating pressure

bar

1,0

1,0

1,0

1,0

1,0

1,0

1,0

Test pressure

bar

1,3

1,3

1,3

1,3

1,3

1,3

1,3

Back pressure

bar

0,5

0,5

0,5

0,5

0,5

0,5

0,5

Weight

kg

3,7

10,5

21

26

36

52

102

Bypass

1“

2“

2,5“

2,5“

2,5“

2,5“

2,5“


ULK,PULK Cone Inflatable Drain Pipe Stoppers
