Halfround Pipe Stoppers UR | Inflatable Pipe Stoppers UK

Halfround Pipe Stoppers UR | Inflatable Pipe Stoppers UK
CategoriesPipe Stopper
AlbumView larger image
BrandIPS
ModelUR
Terms of PaymentT/T, Western Union, MoneyGram
Download DOC
Update Time2019-03-19
Detail Information


These pipe stoppers are due to their lenght suitable for sealing of hause connections and domestic pipe systems. Owning to their shape, they are easy install in pipelines with bends. Because they are short the airrequirement is low and easy ensured by foot or hand pump. The standard product line cover a range from 50 to 200 milimetres.

Halfround Pipe Stoppers UR | Inflatable Pipe Stoppers UK

Halfround Pipe Stoppers UR


Type

UR 5/7

UR 7/10

UR 10/15

UR 15/20

Part - No.

9109

9110

9042

9094

Pipe diameter

mm

50–70

70–100

100–150

150–200

Operating pressure

bar

2,5

2,5

2,5

2,5

Test pressure

bar

3,3

3,3

3,3

3,3

Back pressure

bar

0,5

0,5

0,5

0,5

Diameter

mm

46

67

90

140

Cylinder length

mm

95

100

120

170

Total length

mm

140

155

180

230

Weight

kg

0,3

0,4

0,5

1
