These pipe stoppers are used for sealing of pipelines with a restricted inlet area. Owning to their shape and flexibility they enable easy instalation. Leak tests of house connections with air or water with these pipe stoppers are very easy, too. The standard product line cover a range from 50 to 200 milimetres.


Test Skittle Pipe Stoppers UE,PUE | Water Pipe PlugSkittle Pipe Stoppers UE


Type

UE 5/9

UE 8/15

UE 12/20

Part - No.

1705

1701

1702

Pipe diameter

mm

50–90

80–150

120–200

Operating pressure

bar

2,5

2,0

1,5

Test pressure

bar

3,5

2,6

2,0

Back pressure

bar

1,0

1,0

1,0

Diameter

mm

48

78

116

Length

mm

300

380

520

Total length

mm

350

430

570

Opening for insertion

mm

35

40

50

Weight

kg

0,35

0,48

0,95



Test Skittle Pipe Stoppers PUE


Type

PUE 5/9

PUE 8/15

PUE 12/20

Part - No.

1706

1703

1704

Pipe diameter

mm

50–90

80–150

120–200

Operating pressure

bar

2,5

2,0

1,5

Test pressure

bar

3,5

2,6

2,0

Back pressure

bar

1,0

1,0

1,0

Diameter

mm

48

78

116

Length

mm

300

380

520

Total length

mm

520

600

770

Opening for insertion

mm

35

40

50

Weight

kg

0,55

0,68

1,17

Bypass

mm

4

4

6
