Detail Information

These pipe stoppers are used for sealing egg–shaped sections and they are also suitable for the use in leak tests with water or air. These stoppers are manufactu- red in two forms. The forms that copy the shape of the pipe and the cushion-shaped forms. The former ones are commonly used for smaller sections while the latter are suitable for larger sections because they can by install to sewerages through the standard gullies.The standard product line consists of 13 models each of different size.



Egg–shaped Test Pipe Stoppers UV, UVP,PUV, PUV–F and PUVP | Copper Pipe Stopper | Rubber Pipe Stopper

Egg–shaped Pipe Stoppers UV, UVP

Type

UV 30/45 40/60

UV

50/75 60/90

UV 70/105 90/135

UVP 50/75 60/90

UVP 70/105 90/135

Part - No.

1601

1602

1603

1604

1605

Sealing cross - section

mm

300–400

450–600

500–600

750–900

700–900

1050–1350

500–600

750–900

700–900

1050–1350

Operating pressure

bar

1

1

1

1

1

Test pressure

bar

1,3

1,3

1,3

1,3

1,3

Back pressure

bar

0,5

0,5

0,5

0,5

0,5

Dimensions (w x h x l)

mm

270 x 380 x 800

470 x 690 x 1060

650 x 960 x 1360

700 x 2100

1000 x 2500

Weight

kg

10

35

52

18

26



Egg–shaped Test Pipe Stoppers UV, UVP,PUV, PUV–F and PUVP | Copper Pipe Stopper | Rubber Pipe Stopper

Egg–shaped Test Pipe Stoppers PUV, PUV–F and PUVP

Type

PUV

30/45 40/60

PUV

50/75 60/90

PUV

70/105 90/135

PUV

30/45 40/60 F

PUV

50/75 60/90 F

PUV

70/105 90/135 F

PUVP

50/75 60/90

PUVP

70/105 90/135

Part - No.

1303

1301

1302

1304

1305

1306

1307

1308

Sealing

cross - section

mm

300–400

450–600

500–600

750–900

700–900

1050–1350

300–400

450–600

500–600

750–900

700–900

1050–1350

500–600

750–900

700–900

1050–1350

Operating

pressure

bar

1

1

1

1

1

1

1

1

Test

pressure

bar

1,3

1,3

1,3

1,3

1,3

1,3

1,3

1,3

Back pressure

bar

0,5

0,5

0,5

0,5

0,5

0,5

0,5

0,5

Dimensions

(w x h x l)

mm

280 x 410 x 750

470 x 690 x 880

650 x 960 x 1060

270 x 380 x 800

470 x 690 x 1060

650 x 960 x 1360

700 x 2100

1000 x 2500

Weight

kg

36

48

65

12

38

56

21

30

Bypass

1x1“

1x2“

1x1“

1x2,5“

1x1“

1x2,5“

1x1“

1x2“

2x2“

2x2“

2“

2“
