If the standard sealing pipe stoppers cannot be used due to high back pressure, these high pressure pipe stoppers are recommendable. Higher operational pressure is ensured by the special Kevlar reinforcement  used in all the stoppers. The diame- ter of the standard product line ranges from 50 to 600 millimetres.


High–Pressure Pipe Stoppers UU | Pneumatic Pipe Plug

High–Pressure Pipe Stoppers UU 6 bar


Type

UU 5/7

UU 7/10

UU 10/15

UU 15/20

UU 20/30

UU 30/40

UU 50/60

Part - No.

1119

1113

1114

1115

1116

1117

1118

Pipe diameter

mm

50–70

70–100

100–150

150–200

200–300

300–400

500–600

Operating pressure

bar

6

6

6

6

6

6

6

Test pressure

bar

7,8

7,8

7,8

7,8

7,8

7,8

7,8

Back pressure

bar

3

3

3

3

3

3

3

Diameter

mm

47

67

96

135

190

290

450

Cylinder length

mm

340

330

510

550

580

730

1050

Total length

mm

390

380

570

610

640

790

1130

Weight

kg

0,5

0,6

1,5

2,5

4,9

8,5

25


High–Pressure Pipe Stoppers UU 12 bar


Type

UU 7/9

UU 10/13

UU 14/17

UU 20/25

UU 30/35

Part - No.

1129

1130

1131

1132

1133

Pipe diameter

mm

70–90

100–130

140–170

200–250

300–350

Operating pressure

bar

12

12

12

12

12

Test pressure

bar

16

16

16

16

16

Back pressure

bar

10

10

10

10

10

Diameter

mm

67

96

135

190

290

Cylinder length

mm

330

510

550

580

730

Total length

mm

380

570

610

640

790

Weight

kg

0,6

1,5

2,5

4,9

8,5
