Endoscope CCTV Detection Drain Inspection Camera System
| Categories | Push Camera P40 |
|---|---|
| Brand | SROD |
| Model | P50B |
| Type | Digital Camera |
| Style | Sewer camera |
| Sensor | CCD |
| Technology | Pan / Tilt / Zoom |
| Special Features | Waterproof / Weatherproof |
| Camera head diameter | 50mm |
| Resolution | 480TVL |
| CCD type | SONY CCD |
| Pan and tilt | 360 degree 180 degree |
| Waterproof | IP68 |
| Terms of Payment | T/T, Western Union, MoneyGram |
| Download DOC |  |
| Update Time | June 2,2023 |
Our push rod drain camera are very useful for inspection of pipeline, sewer pipe, normal pipeline, broken pipe, tank, vessels, Ventilation tube and so on.
Application | This drain camera is usually for pipes diameter from 60mm to 400mm. | |
Model | SD-1050II | |
Camera | CCD Type | SONY CCD |
Horizontal resolution | 480TVL | |
Diameter | 50mm | |
Pan &Tilt | Pan: 360degrees; Tilt: 180degrees | |
Auto level | Auto | |
Focus | Manual | |
Optical system | 2.8mm | |
LED Lights | LED Lights | Bright 18 pcs LED SMD |
Brightness of the LEDS | Controllable | |
Display&Storage system | Size of the screen | 5.7’’ TFT Monitor |
Brightness | 500cd/m2 | |
Resolution | 640*480 | |
Video format | MPEG4/AVI | |
Picture format | MPEG | |
Memory card | 4G(up to 32G) | |
USB interface | USB output | |
Character input | ||
Video | Resolution | 720*576 |
Meter counter | The distance will be displayed on the screen (Optional) | |
Cable | Length | 30-140m (optional) |
Bracket | Centering | To make sure the camera is in the center of the pipe |
Power supply | chargeable Battery | DC12V/14.8V 13500mah |
Camera Head :
Camera head with skids:
Customers can customize a camera heads with different sizes brackets.
Transmiter is Optional
5.7'' TFT Screen Allows Text Overlay
IPS was started with a simple goal ,to provide our Chinese customers ,who were engaded in water monitoring and/or municipal sewer line inspection and rehabilitation ,with affordable devices.
* In 2009,we began our business with self-made multi-direction endoscope.But it was not very sucessful at that time.
* In 2013,we came back with SINGA crawlers,which was equipped with powerful illumination to capture and record pipe defects.
* In2015,we added explosion-proof and motor-driven cable drum to our carriage.And setted out to develop our own UV curing,3D sonar/laser system.
Thanks to continuous efforts in customers' oriented technical innovations and excellent service ,IPS has witnessed a series of huge success.Now we are the leading manufacturer of pipeline CCTV inspection equipment in China ,and we are ready to lead international pipe inspection&rehabilitation industry in the future.
